Light source:

Bulb: 1200 w short arc gas discharge

Lamp holder: GY - 22

Available models: PHILIPS 1200 SA MSR

Control: automatic and remote on/off

Rectifier: electromagnetic ballast

S electrical parameters:

Power supply:

208/230/250 v, 50 hz, 208/230 v, 60 hz

Power: 1500 w, 220 v / 50 hz

Working temperature:

Maximum temperature: 40 DHS 104 DHS (F) C

Maximum surface temperature; 135 DHS C 275 DHS (F)

S mechanical parameters:

Height: 619 mm

Width: 536 mm

Deep: 616 mm

50 kg net weight:

Gross weight: 83 kg (including air box)

S control and programming:

Communication protocol: the USITT DMX - 512

The control channel: 24 or 32

Display: LCD display pattern

Horizontal/vertical accuracy: 8 or 16 bit

Design positioning: 8 or 16 bit

Prism location: 8 or 16 bit

Mobile control: tracing and vector

Data input/output: the three cores and five cores for money

S electromechanical effect:

Green: 0-100%

Magenta: 0-100%

Huang: 0-100%

The CTO: 0-100%

Color wheel: six replaceable color + white light

Design of wheel 1:6 replacement glass design + white light

Design round 2:6 replacement glass design + white light

Pattern piece size: 37 mm

Aperture: electric, linear

Round effect: 4 + white light replaceable prism and effect

Atomizing effect: independence, adjustable

Dimmer/strobe: linear dimming and adjustable speed stroboscope

Level: 530 degrees

Vertical: 280 degrees
