Technical parameters

Voltage: 90 v - 264 - v / 47 hz - 63 hz (on-demand customized) liquid crystal display in both Chinese and English

Ballast: magnetic induction

Bulb: PHILIPS: MSI (color temperature) : 1200 5600 k MSI 5600 w/S (color temperature) : 6000 k OSRAM: HMI1200W XS/S (color temperature) : 6000 k

HMI1200W/GS (color temperature) : 6000 k

Total power: 1400 w signal: DMX 1400 channels: 18 (16 bit), 16 (8 bit) vertical single lamp: 580 x470x935 (mm)

Double lamp hangs (LxWxH) : 820 x580x935 (mm) single lamp (LxWxH) : 530 x506x 758 (mm) net weight: 48.5 KG (MR) 55.5 KG (MRE) gross weight: 51.2 KG (MR) 53.2 KG (MRE)

Motor: 16 performance characteristics

Control table can be individually controlled motor self-checking, automatic reset

Controller can control the lamp body DMX address function display stand, stand, and DMX signal, turn off when the indicator lamp light

Adjustable aperture size shrinkage function (the light beam can be adjust the size according to the field programming requirement)

Eight kinds of main colour + 8 types of mixed color, at the same time as a high-speed one-way rolling effect

0-100% mechanical linear dimming (can control the effect of shading to full medallion)

1-7 times/SEC ultra-high speed stroboscopic effect

Vertical level of 540 degrees, 250 degrees of scanning range, movements smooth, fluent, accurate positioning

Horizontal and vertical movement direction can be adjusted accurately the position and velocity

Cut each channel has light function (can be used in the preparation of fixed point for a special effect)

Eight beautiful fixed metal logo + (white light)

Paragraphs 2 rotating glass design + 4 beautiful rotating metal logo + (white light) (can be customized according to customer requirements)

Can adjust freely and reverse, speed rotating pattern

Rotating pattern Angle can be adjusted separately (to ensure the consistency between design direction Angle)

Using infinite zoom zoom function is 13 degrees to 32 degrees, can be arbitrary regulation

Prism (renewable) have positive and reverse rotate function

Six fan cooling, cold air from the lamp head part into the bulb fever warehouse, keep the lamp head of the parts in low temperature environment can prolong the service life, and can make the light bulbs emit heat can be directly discharge in a timely manner to ensure that the entire lamp body always stay at the design temperature range, the built-in overheating protection, good heat dissipation fully

PFC power factor compensation, even in the voltage fluctuation (plus or minus 10 v) under the environment of use

Compliance with the safety standards of various, IP20 protection level, the power cord accord with the standard CE20/22

The electronic ballast can reduce light weight at least 7 kg (on the basis of actual configuration)

Quick and easy installation, using a set of a quarter of a spin lock, solid security (on the basis of actual configuration)
