12 DMX512 control channel, channel

Voltage: AC210 ~ 240 v, 50 ~ 60 Hz (90-130 - v) can be customized

Light bulbs: JENBO 300/2 FASTFIT

(850 k color temperature: life: 850 hours)

Horizontal: 540 ° (scan) 16 bit precision electronic error correction

Vertical scanning: 270 ° (scan) 16 bit precision electronic error correction

Color plate: 8 plug type color + white light, unidirectional rotation with rainbow effect, two and half color walk panchromatic mode switches

Pluggable pattern piece: 8 piece + white light plug type design, with two-way rotation of rainbow effect

Stroboscopic: double pole stroboscopic frequency up to 13 times per second, and can choose random stroboscopic and pulse frequency flash

Linear atomization atomization: 0% ~ 100%

Display: beautiful red dot matrix display

Homemade switching power supply, make the product is lighter, more stable performance, short circuit protection automatically controller reset function, with the function of delay

Product size: 39.6 * 39 * 63 cm

Carton size: 44 * 51.5 * 51.5 cm

Air box size: 47 * 47 * 78.5 cm (single), 47 * 92 * 78.5 cm) (two pens

Net weight: 17 kg

19 kg gross weight:

Channel:

CH1: X

CH2: Y

CH3: X/Y axis speed

CH4, stroboscopic

CH5: medallion

CH6: color piece of dish

CH7, pattern plate

CH8: design of vibration

CH9: atomization

Fine-tuning CH10: X

CH11: Y fine-tuning

CH12: reset
